The CradlePoint IBR200 Series is a compact, semi-rugged 4G LTE router built for secure IoT connectivity. It features an embedded Category 1 LTE modem (10 Mbps DL / 5 Mbps UL), single‑band 2.4 GHz Wi‑Fi (802.11b/g/n), 1 × 10/100 Mbps Ethernet port, 1 × USB 2.0 Type A, GPIO (1 input/1 output),...
More
CradlePoint IBR200 Series - Wireless Router - WWAN 2.4 GHz
Product Code: 1173701493
Available in 4 - 6 days
462,28 €
or
14,44€ / month
εως 36 δόσεις με πιστωτική κάρτα
With the purchase of this product you earn 1387 Bytes
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
Έως 36 Δόσεις. Δείτε το πλάνο δόσεων:
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
The CradlePoint IBR200 Series is a compact, semi-rugged 4G LTE router built for secure IoT connectivity. It features an embedded Category 1 LTE modem (10 Mbps DL / 5 Mbps UL), single‑band 2.4 GHz Wi‑Fi (802.11b/g/n), 1 × 10/100 Mbps Ethernet port, 1 × USB 2.0 Type A, GPIO (1 input/1 output), passive GNSS, and a metal semi-rugged enclosure. Supports WPA/WPA2 Personal and WPA2 Enterprise, RADIUS/TACACS+, IPsec VPN (up to 2 concurrent tunnels), VLANs, DHCP, DynDNS, and remote management via Ericsson NetCloud Service for IoT. Operating range -20°C to 60°C. SKU: 21187875, MPN: TB3-020010M-EWM, EAN: 0810007801841.
-
ModelIBR200 Series
-
BrandCradlepoint
-
SKU21187875
-
MPNTB3-020010M-EWM
-
EAN / UPC0810007801841
-
Product Type4G LTE IoT Router (semi-rugged)
-
Cellular ModemCategory 1 LTE (3GPP Rel. 10)
-
LTE Data Rates10 Mbps downlink / 5 Mbps uplink
-
SIM SupportSingle SIM slot, 2FF (Mini)
-
3G/2G SupportWCDMA/UMTS/HSPA+ (3G); No 2G
-
Wi‑Fi Standard802.11b/g/n (Wi‑Fi 4)
-
Wi‑Fi Frequency2.4 GHz (single radio)
-
Wi‑Fi Max Speed72 Mbps (2.4 GHz)
-
AntennaExternal 1x1 RP‑SMA
-
SSIDsUp to 2
-
Max Connected ClientsUp to 16
-
Ethernet Ports1 × FE (10/100 Mbps, LAN)
-
USB1 × USB 2.0 Type A (5V, 500mA)
-
GPIO2 pins (1 input, 1 output)
-
GNSSPassive GNSS (region-dependent)
-
Firewall Throughput60 Mbps (stateful)
-
IPsec VPN Throughput10 Mbps
-
Max Concurrent VPN Tunnels2
-
VPNIPsec (IKEv2 with MOBIKE), GRE supported
-
VLAN Support802.1Q VLAN tagging
-
DHCPServer/Client/Relay
-
IPv6Supported
-
NATNAT-less routing option available
-
ManagementEricsson NetCloud Service for IoT (subscription)
-
Advanced FeaturesFailover/Failback, Standby, Wi‑Fi as WAN, IP Passthrough, QoS
-
Power Input12 VDC / 1 A (power adapter)
-
Power Consumption Idle~2.7 W (1.8 W with Wi‑Fi off)
-
Typical Power~3.6 W
-
Heavy Usage Power~5.8 W
-
Operating Temperature-20°C to 60°C
-
Dimensions76.5 × 94.5 × 24.5 mm
-
Weight175 g
-
EnclosureMetal, semi-ruggedized
-
MountingIntegrated mounting holes
-
CertificationsPTCRB, GCF, FCC (Wi‑Fi), AT&T, Verizon (regions)
-
Use CasesPlant controls, surveillance cameras, digital signage, kiosks, ATMs, IoT endpoints
Ratings
Description
The CradlePoint IBR200 Series is a compact, semi-rugged 4G LTE router built for secure IoT connectivity. It features an embedded Category 1 LTE modem (10 Mbps DL / 5 Mbps UL), single‑band 2.4 GHz Wi‑Fi (802.11b/g/n), 1 × 10/100 Mbps Ethernet port, 1 × USB 2.0 Type A, GPIO (1 input/1 output), passive GNSS, and a metal semi-rugged enclosure. Supports WPA/WPA2 Personal and WPA2 Enterprise, RADIUS/TACACS+, IPsec VPN (up to 2 concurrent tunnels), VLANs, DHCP, DynDNS, and remote management via Ericsson NetCloud Service for IoT. Operating range -20°C to 60°C. SKU: 21187875, MPN: TB3-020010M-EWM, EAN: 0810007801841.
Technical Specifications
-
ModelIBR200 Series
-
BrandCradlepoint
-
SKU21187875
-
MPNTB3-020010M-EWM
-
EAN / UPC0810007801841
-
Product Type4G LTE IoT Router (semi-rugged)
-
Cellular ModemCategory 1 LTE (3GPP Rel. 10)
-
LTE Data Rates10 Mbps downlink / 5 Mbps uplink
-
SIM SupportSingle SIM slot, 2FF (Mini)
-
3G/2G SupportWCDMA/UMTS/HSPA+ (3G); No 2G
-
Wi‑Fi Standard802.11b/g/n (Wi‑Fi 4)
-
Wi‑Fi Frequency2.4 GHz (single radio)
-
Wi‑Fi Max Speed72 Mbps (2.4 GHz)
-
AntennaExternal 1x1 RP‑SMA
-
SSIDsUp to 2
-
Max Connected ClientsUp to 16
-
Ethernet Ports1 × FE (10/100 Mbps, LAN)
-
USB1 × USB 2.0 Type A (5V, 500mA)
-
GPIO2 pins (1 input, 1 output)
-
GNSSPassive GNSS (region-dependent)
-
Firewall Throughput60 Mbps (stateful)
-
IPsec VPN Throughput10 Mbps
-
Max Concurrent VPN Tunnels2
-
VPNIPsec (IKEv2 with MOBIKE), GRE supported
-
VLAN Support802.1Q VLAN tagging
-
DHCPServer/Client/Relay
-
IPv6Supported
-
NATNAT-less routing option available
-
ManagementEricsson NetCloud Service for IoT (subscription)
-
Advanced FeaturesFailover/Failback, Standby, Wi‑Fi as WAN, IP Passthrough, QoS
-
Power Input12 VDC / 1 A (power adapter)
-
Power Consumption Idle~2.7 W (1.8 W with Wi‑Fi off)
-
Typical Power~3.6 W
-
Heavy Usage Power~5.8 W
-
Operating Temperature-20°C to 60°C
-
Dimensions76.5 × 94.5 × 24.5 mm
-
Weight175 g
-
EnclosureMetal, semi-ruggedized
-
MountingIntegrated mounting holes
-
CertificationsPTCRB, GCF, FCC (Wi‑Fi), AT&T, Verizon (regions)
-
Use CasesPlant controls, surveillance cameras, digital signage, kiosks, ATMs, IoT endpoints
