CPU Intel S1700 CORE i3 12100 TRAY 4x3,3 60W GEN12

Description

Technical Specifications

• Processor Family
  12th Generation Intel Core i3 processors
• Processor Socket
  LGA 1700
• Processor Manufacturer
  Intel
• Number of Processor Cores
  4
• Number of Performance Cores
  4
• Number of Efficient Cores
  0
• Total Threads
  8
• Max Turbo Frequency
  4.3 GHz
• Performance Core Max Turbo Frequency
  4.3 GHz
• Performance Core Base Frequency
  3.3 GHz
• Cache
  12 MB Intel Smart Cache
• Total L2 Cache
  5 MB
• Processor Base Power
  60 W
• Maximum Turbo Power
  89 W
• Memory Channels
  Dual Channel
• Maximum Internal Memory Supported by Processor
  128 GB
• Memory Types Supported by Processor
  DDR4-SDRAM, DDR5-SDRAM
• Memory Bandwidth (Max)
  76.8 GB/s
• On-board Graphics Adapter Model
  Intel UHD Graphics 730
• On-board Graphics Adapter Supported Outputs
  Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
• On-board Graphics Adapter Base Frequency
  300 MHz
• Direct Media Interface (DMI) Revision
  4
• Max # of DMI Lanes
  8
• PCI Express Revision
  5.0 and 4.0
• PCI Express Configurations
  Up to 1x16+4, 2x8+4
• Max # of PCI Express Lanes
  20
• Sockets Supported
  LGA 1700
• Max CPU Configuration
  1
• Thermal Solution Specification
  PCG 2020C
• TJUNCTION
  100°C
• Package Size
  45.0 mm x 37.5 mm
• Intel Thread Director
  No
• Intel Deep Learning Boost
  Yes
• Intel Speed Shift Technology
  Yes
• Intel Turbo Boost Technology
  2.0
• Intel Hyper-Threading Technology
  Yes
• Intel Virtualization Technology (VT-x)
  Yes
• Intel Virtualization Technology for Directed I/O (VT-d)
  Yes
• Intel VT-x with Extended Page Tables (EPT)
  Yes
• Intel 64
  Yes
• Instruction Set Extensions
  SSE4.1, SSE4.2, AVX2
• Idle States
  Yes
• Enhanced Intel SpeedStep Technology
  Yes
• Thermal Monitoring Technologies
  Yes
• Intel Volume Management Device (VMD)
  Yes
• Intel AES New Instructions
  Yes
• Secure Key
  Yes
• Intel OS Guard
  Yes
• Execute Disable Bit
  Yes
• Intel Boot Guard
  Yes
• Mode-based Execute Control (MBEC)
  Yes
• Intel Control-Flow Enforcement Technology
  Yes
