Bluetooth OBD2 ELM327 Peiying DM-4058 — compact Bluetooth car diagnostic interface that plugs into the vehicle OBD2 port. Features include read and clear diagnostic trouble codes (DTC), Freeze Frame support, live data streaming and logging, graphical parameter display, real-time parameter...
More
Bluetooth OBD2 ELM327 Car Diagnostic Interface Peiying DM-4058
Product Code: 1143722802
Upon Order
21,24 €
With the purchase of this product you earn 64 Bytes
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
Bluetooth OBD2 ELM327 Peiying DM-4058 — compact Bluetooth car diagnostic interface that plugs into the vehicle OBD2 port. Features include read and clear diagnostic trouble codes (DTC), Freeze Frame support, live data streaming and logging, graphical parameter display, real-time parameter monitoring, I/M readiness, Mode 6 diagnostics, lambda sensor readout and vehicle battery voltage monitoring. Wireless connection via Bluetooth. Power: 12 V, typical current 16 mA. Operating temperature -40°C to +85°C. Device dimensions 45 x 25 x 70 mm, weight 31 g. Supported protocols: SAE J1850 PWM/VPW, ISO9141-2, ISO14230-4 (KWP), ISO15765-4 CAN (11/29 bit, 250/500 Kbaud). Compatible with OBD2-capable passenger vehicles.
-
BrandPeiying
-
ModelDM-4058
-
SKUDM-4058
-
EAN5901890125758
-
MPNDM-4058
-
Interface TypeOBD2 male plug (connects to vehicle OBD-II port)
-
CommunicationBluetooth
-
ELM ChipsetELM327-compatible
-
Supported ProtocolsSAE J1850 PWM (41.6 Kbaud), SAE J1850 VPW (10.4 Kbaud), ISO9141-2, ISO14230-4 KWP (5 baud & fast init), ISO15765-4 CAN (11-bit/29-bit, 250/500 Kbaud)
-
FunctionsRead/Clear DTCs, Freeze Frames, Live Data (real-time), Data Logging, Graphical parameter display, I/M Readiness, Mode 6 diagnostics, Lambda sensor readout, Battery voltage monitoring
-
Operating Voltage12 V
-
Quiescent Current16 mA
-
Operating Temperature Range-40°C to +85°C
-
Device Dimensions45 x 25 x 70 mm
-
Product Weight31 g
-
Package Weight (est.)50 g
-
ConnectorStandard OBD2 16-pin male
-
CompatibilityOBD-II compliant passenger vehicles
-
ColorBlack
-
Housing MaterialPlastic
Ratings
Description
Bluetooth OBD2 ELM327 Peiying DM-4058 — compact Bluetooth car diagnostic interface that plugs into the vehicle OBD2 port. Features include read and clear diagnostic trouble codes (DTC), Freeze Frame support, live data streaming and logging, graphical parameter display, real-time parameter monitoring, I/M readiness, Mode 6 diagnostics, lambda sensor readout and vehicle battery voltage monitoring. Wireless connection via Bluetooth. Power: 12 V, typical current 16 mA. Operating temperature -40°C to +85°C. Device dimensions 45 x 25 x 70 mm, weight 31 g. Supported protocols: SAE J1850 PWM/VPW, ISO9141-2, ISO14230-4 (KWP), ISO15765-4 CAN (11/29 bit, 250/500 Kbaud). Compatible with OBD2-capable passenger vehicles.
Technical Specifications
-
BrandPeiying
-
ModelDM-4058
-
SKUDM-4058
-
EAN5901890125758
-
MPNDM-4058
-
Interface TypeOBD2 male plug (connects to vehicle OBD-II port)
-
CommunicationBluetooth
-
ELM ChipsetELM327-compatible
-
Supported ProtocolsSAE J1850 PWM (41.6 Kbaud), SAE J1850 VPW (10.4 Kbaud), ISO9141-2, ISO14230-4 KWP (5 baud & fast init), ISO15765-4 CAN (11-bit/29-bit, 250/500 Kbaud)
-
FunctionsRead/Clear DTCs, Freeze Frames, Live Data (real-time), Data Logging, Graphical parameter display, I/M Readiness, Mode 6 diagnostics, Lambda sensor readout, Battery voltage monitoring
-
Operating Voltage12 V
-
Quiescent Current16 mA
-
Operating Temperature Range-40°C to +85°C
-
Device Dimensions45 x 25 x 70 mm
-
Product Weight31 g
-
Package Weight (est.)50 g
-
ConnectorStandard OBD2 16-pin male
-
CompatibilityOBD-II compliant passenger vehicles
-
ColorBlack
-
Housing MaterialPlastic
