The truck axle is a critical component of a heavy-duty vehicle, designed to support weight and provide the necessary torque for movement. This axle is part of a larger axle system that includes various key components.

Key Features:

• Axle Type: Commonly includes front, single rear, and tandem configurations.
• Capacity: Handles loads from 3,175 kg to 9,072 kg.
• Design Variations: Includes features for enhanced strength and durability.

The axle housing is typically made from cast material for durability, with wall thickness ranging from 8 mm to 16 mm. The axle shaft specifications include spline sizes around 57.2 mm to 60.5 mm with variable ring gear sizes.

Performance Ratings:

• Gross Combined Weight (GCW): Ranges from 26,332 kg to 31,780 kg.
• Turning Radius: About 6023 mm to counterweight and 5985 mm to the outside of the tires.

In conclusion, the truck axle is designed to manage significant loads and provide torque necessary for optimal vehicle performance. A clear understanding of its specifications ensures it meets heavy-duty application requirements.
