The ATC-ST2 DVB-T HD Modulator by Atc converts digital H.264 video streams into DVB-T RF carriers. It supports 64QAM modulation, 7/8 MHz bandwidth, 8K FFT, 1/32 guard interval and 2/3 code rate with MER >28 dB. Frequency coverage is 174–230 MHz and 470–862 MHz, RF output impedance 75 Ω, powered by...
More
Atc ATC-ST2 DVB-T HD Modulator
Product Code: 1172727701
Available in 4 - 6 days
120,90 €
or
3,78€ / month
εως 36 δόσεις με πιστωτική κάρτα
With the purchase of this product you earn 363 Bytes
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
Έως 36 Δόσεις. Δείτε το πλάνο δόσεων:
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
The ATC-ST2 DVB-T HD Modulator by Atc converts digital H.264 video streams into DVB-T RF carriers. It supports 64QAM modulation, 7/8 MHz bandwidth, 8K FFT, 1/32 guard interval and 2/3 code rate with MER >28 dB. Frequency coverage is 174–230 MHz and 470–862 MHz, RF output impedance 75 Ω, powered by DC 5V/1A. Supports HD resolution and H.264 encoding at 5–15 Mb/s. Suited for CCTV distribution, IPTV/hotel TV systems and other professional RF distribution applications.
-
BrandAtc
-
ModelATC-ST2
-
Product TypeDVB-T HD Modulator
-
Modulation64QAM
-
Channel Bandwidth7 / 8 MHz
-
FFT8K
-
Guard Interval1/32
-
Code Rate2/3
-
MER>28 dB
-
Frequency Range174–230 MHz, 470–862 MHz
-
RF Output Impedance75 Ω
-
RF Output LevelAdjustable
-
Video FormatHD
-
Compression CodecH.264
-
Bitrate5–15 Mb/s
-
Power SupplyDC 5V / 1A
-
Operating Temperature0 ~ +50°C
-
Typical ApplicationsCCTV distribution, IPTV, hotel TV systems, internal RF broadcast
-
SKU03.001.0101
-
EAN5200149941355
-
MPNATC-ST2
Ratings
Description
The ATC-ST2 DVB-T HD Modulator by Atc converts digital H.264 video streams into DVB-T RF carriers. It supports 64QAM modulation, 7/8 MHz bandwidth, 8K FFT, 1/32 guard interval and 2/3 code rate with MER >28 dB. Frequency coverage is 174–230 MHz and 470–862 MHz, RF output impedance 75 Ω, powered by DC 5V/1A. Supports HD resolution and H.264 encoding at 5–15 Mb/s. Suited for CCTV distribution, IPTV/hotel TV systems and other professional RF distribution applications.
Technical Specifications
-
BrandAtc
-
ModelATC-ST2
-
Product TypeDVB-T HD Modulator
-
Modulation64QAM
-
Channel Bandwidth7 / 8 MHz
-
FFT8K
-
Guard Interval1/32
-
Code Rate2/3
-
MER>28 dB
-
Frequency Range174–230 MHz, 470–862 MHz
-
RF Output Impedance75 Ω
-
RF Output LevelAdjustable
-
Video FormatHD
-
Compression CodecH.264
-
Bitrate5–15 Mb/s
-
Power SupplyDC 5V / 1A
-
Operating Temperature0 ~ +50°C
-
Typical ApplicationsCCTV distribution, IPTV, hotel TV systems, internal RF broadcast
-
SKU03.001.0101
-
EAN5200149941355
-
MPNATC-ST2
