The ATC-85 is a compact, rack-mount 24V power supply/power inserter designed for antenna and RF installations. It operates across the 5–862 MHz frequency range and features 1 x F female input and 2 x F female outputs. Key specifications: insertion loss 1.5 dB, isolation attenuation ≥25 dB,...
More
ATC-85 24V Power Supply 2DIN - Atc
Product Code: 1172727682
Available in 4 - 6 days
10,73 €
With the purchase of this product you earn 33 Bytes
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
The ATC-85 is a compact, rack-mount 24V power supply/power inserter designed for antenna and RF installations. It operates across the 5–862 MHz frequency range and features 1 x F female input and 2 x F female outputs. Key specifications: insertion loss 1.5 dB, isolation attenuation ≥25 dB, return-loss attenuation ≥10 dB. Mains input 110–240V AC (50/60Hz). DC output 24V / 150 mA. The unit is designed for DIN rail mounting (2DIN) and is suitable for powering active antennas or amplifiers in domestic or professional setups.
-
Product TypePower supply / Power inserter
-
BrandAtc
-
ModelATC-85
-
Mounting Type2 DIN (DIN rail) module
-
Frequency Range5–862 MHz
-
Input Voltage (AC)110–240V AC (50/60Hz)
-
Output Voltage (DC)24V
-
Output Current150 mA
-
Input Connector1 x F (female)
-
Output Connectors2 x F (female)
-
Insertion Loss1.5 dB
-
Isolation Attenuation≥25 dB
-
Return Loss Attenuation≥10 dB
-
Intended UsePowering active antennas/amplifiers for domestic or professional installations
-
Package Weight250 g
-
Product Weight180 g
-
Package Dimensions (L×W×H)12×8×4 cm
Ratings
Description
The ATC-85 is a compact, rack-mount 24V power supply/power inserter designed for antenna and RF installations. It operates across the 5–862 MHz frequency range and features 1 x F female input and 2 x F female outputs. Key specifications: insertion loss 1.5 dB, isolation attenuation ≥25 dB, return-loss attenuation ≥10 dB. Mains input 110–240V AC (50/60Hz). DC output 24V / 150 mA. The unit is designed for DIN rail mounting (2DIN) and is suitable for powering active antennas or amplifiers in domestic or professional setups.
Technical Specifications
-
Product TypePower supply / Power inserter
-
BrandAtc
-
ModelATC-85
-
Mounting Type2 DIN (DIN rail) module
-
Frequency Range5–862 MHz
-
Input Voltage (AC)110–240V AC (50/60Hz)
-
Output Voltage (DC)24V
-
Output Current150 mA
-
Input Connector1 x F (female)
-
Output Connectors2 x F (female)
-
Insertion Loss1.5 dB
-
Isolation Attenuation≥25 dB
-
Return Loss Attenuation≥10 dB
-
Intended UsePowering active antennas/amplifiers for domestic or professional installations
-
Package Weight250 g
-
Product Weight180 g
-
Package Dimensions (L×W×H)12×8×4 cm
