Καταγραφικό LevelOne NVR-0508 8-channel

Technical Specifications

• Video input channels
  8 channels
• Video recording modes
  720p, 1080p
• Maximum resolution
  3840 x 2160 pixels
• Number of users
  64 users
• Supported video formats
  H.264, H.264 +, H.265, MPEG4
• Installed operating system
  Embedded LINUX
• Number of fans
  1 fan
• Throughput data rate
  160 Mbit / s
• WIRELESS INTERNET ACCESS
  no
• Maximum number of HDDs supported
  2
• Max. Storage capacity
  12 TB
• HDD interface
  SATA
• Network standard
  IEEE 802.3at
• Supported network protocols
  TCP, UDP, IPv4, IPv6, Http, Https, SMTP, NTP, SNTP
• Number of Ethernet LAN ports (RJ-45)
  9
• Ethernet LAN data transfer rates
  10,100,1000 Mbit / s
• Power over Ethernet (PoE)
  yes
• Number of Power over Ethernet (PoE) connections
  8th
• HDMI output
  yes
• VGA (D-Sub) output connectors
  1
• Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports
  2
• Audio RCA inputs
  1
• Audio RCA outputs
  1
• Country of origin
  China
• Certification
  CE, FCC, ISO9001, ISO14001, uL
• Rack installation
  yes
• Product color
  black
• LED indicators
  Alarm, hard drive, performance
• On / off switch
  yes
• Operating temperature range
  -10 - 55 ° C
• Humidity in operation
  10 - 90%
• Power consumption (in operation)
  180 W
• AC input voltage
  100 - 230 V.
• Supported browser
  Internet Explorer 9+
• Width of the shipping box
  54.8 cm
• Length of the shipping box
  45 cm
• Height of the shipping box
  41.2 cm
• Shipping box weight
  14.1 kg
• Quantity per shipping box
  4 piece (s)
• AC power adapter
  yes
• Supplied cables
  AC
• Manual on CD
  yes
• Packaging width
  435 mm
• Packaging depth
  450 mm
• Packing height
  387 mm
• Packaging type
  box
• Package weight
  3.23 kg
• width
  315 mm
• depth
  52 mm
• height
  385 mm
• Weight
  3 kg
