Allnet Switch smart managed Layer2 24 Port • 24x GbE • 4x SFP+ • 19" • Fanless • ALL-SG8428M-10G

Description

Technical Specifications

• Brand
  ALLNET
• Model / MPN
  ALL-SG8428M-10G
• SKU
  21187689
• EAN
  4038816129475
• Switch Type
  Layer 2 Smart Managed Switch
• Ports (RJ45)
  24 x 10/100/1000 Mbps Gigabit Ethernet (RJ-45)
• Uplink Ports
  4 x SFP+ (10GbE) mini-GBIC slots
• Total Switching Ports
  28 (24 RJ45 + 4 SFP+)
• Switching Capacity
  128 Gb/s (non-blocking)
• Forwarding Rate
  Approx. 95.2 Mpps
• MAC Address Table
  16 K entries
• Buffer Memory
  1.536 KB
• Jumbo Frames
  Up to 9K-10K (family manual indicates 10K support)
• Switching Mode
  Store-and-forward
• Management
  Web-based GUI (Web management), CLI (model family manual), SNMP support (family features)
• Layer 2 Features
  VLAN (802.1Q), QoS, Port-based and 802.1X authentication, ACLs, IGMP Snooping, MLD Snooping, DHCP Snooping, Storm Control
• Link Aggregation
  LACP / Static LAG supported
• Spanning Tree
  STP / RSTP / MSTP
• Security
  802.1X Port Authentication, ACLs, DHCP Snooping
• Energy
  IEEE 802.3az Energy Efficient Ethernet supported
• Standards Compliance
  IEEE 802.3, 802.3u, 802.3ab, 802.3z (SFP), IEEE 802.3x flow control
• Form Factor
  19-inch rackmount (1U), metal housing, fanless
• Cooling
  Fanless (passive cooling)
• Mounting
  19" rack and wall mounting supported
• Use Case
  SMB workgroups, enterprise-style layer 2 traffic management and uplinks to servers/storage
• Physical Dimensions (approx.)
  Width 44.5 cm (19"), Height ~4.4 cm (1U), Depth ~24 cm
• Product Weight (approx.)
  3500 g
• Package Weight (approx.)
  5000 g
• Power
  (Not specified in sources) null
• Certifications
  (Not fully listed in sources) null
• Documentation
  User manual and datasheet available (ALLNET FTP/manual)
