The ABUS IP Mini Tube 4 MP (model IPCA34512A) is a compact 4 MP network surveillance camera with a fixed 2.8 mm lens (104° HFOV), integrated infrared and white-light illumination (color night mode), and an IP67-rated metal housing for indoor/outdoor use. It supports 2,688 × 1,520 @25 fps,...
More
ABUS IP Mini Tube 4 MPx, 2.8 mm IR/WL — IPCA34512A
Product Code: 1117796904
Available in 1 - 3 days
344,06 €
or
10,74€ / month
εως 36 δόσεις με πιστωτική κάρτα
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
Έως 36 Δόσεις. Δείτε το πλάνο δόσεων:
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
The ABUS IP Mini Tube 4 MP (model IPCA34512A) is a compact 4 MP network surveillance camera with a fixed 2.8 mm lens (104° HFOV), integrated infrared and white-light illumination (color night mode), and an IP67-rated metal housing for indoor/outdoor use. It supports 2,688 × 1,520 @25 fps, H.264/H.265/MJPEG codecs, three simultaneous streams, PoE (IEEE 802.3af) or 12 V DC power, ONVIF compatibility, microSD local recording (encrypted), and built-in VCA analytics (human/vehicle detection, tripwire, intrusion, area entry/exit). Physical dimensions: 179 × 74 × 75 mm. Typical night illumination range up to 30 m.
-
BrandABUS
-
Model / MPNIPCA34512A
-
SKU599865
-
EAN / Barcode4043158239744
-
Product familyIP Mini Tube
-
Category4 MP IP network surveillance camera (mini-tube / bullet)
-
Image sensor1/1.8-inch Progressive Scan CMOS
-
Maximum resolution2,688 × 1,520 pixels (4 MP)
-
Maximum frame rate25 fps @ 2,688 × 1,520
-
Lens (fixed)2.8 mm
-
Horizontal field of view104°
-
Vertical field of view54°
-
Day/NightICR with automatic switching
-
IlluminationInfrared LEDs + White-light LEDs (full-color night mode)
-
Illumination rangeUp to 30 m (manufacturer specification)
-
Video codecsH.264, H.265, MJPEG
-
StreamsThree simultaneous video streams
-
Stream examplesStream 1: 2,688×1,520 @25 fps; Stream 2: 640×480 @25 fps; Stream 3: 1,920×1,080 up to 10 fps (with VCA disabled)
-
Network interface1 × RJ45 10/100 Mbps (self-adaptive)
-
PoEYes, IEEE 802.3af
-
Power input12 V DC (±25%) or PoE
-
Power consumption≈7 W (typ.)
-
Current consumption~600 mA (at 12 V DC)
-
ONVIFSupported
-
Mobile accessABUS Link Station compatible
-
Local storagemicroSD slot (local recording, encrypted storage supported)
-
AudioAudio support listed by distributor (details not specified by ABUS)
-
VCA / AnalyticsHuman detection, vehicle detection, tripwire, intrusion, area entry/exit
-
Ingress protectionIP67 (weather-resistant)
-
Housing materialMetal
-
Housing colorWhite
-
Dimensions (L×W×H)179 × 74 × 75 mm
-
Operating temperature≈ −30 °C to +60 °C
-
Weight (product)~400 g (estimated)
-
Gross weight (package)0.8 kg (manufacturer datasheet)
-
Mounting styleMini-tube / bullet camera
-
CertificationsNo hazardous-area certification listed
-
Included featuresIR + white-light illumination, encrypted microSD recording, PoE, ONVIF, analytics
Ratings
Description
The ABUS IP Mini Tube 4 MP (model IPCA34512A) is a compact 4 MP network surveillance camera with a fixed 2.8 mm lens (104° HFOV), integrated infrared and white-light illumination (color night mode), and an IP67-rated metal housing for indoor/outdoor use. It supports 2,688 × 1,520 @25 fps, H.264/H.265/MJPEG codecs, three simultaneous streams, PoE (IEEE 802.3af) or 12 V DC power, ONVIF compatibility, microSD local recording (encrypted), and built-in VCA analytics (human/vehicle detection, tripwire, intrusion, area entry/exit). Physical dimensions: 179 × 74 × 75 mm. Typical night illumination range up to 30 m.
Technical Specifications
-
BrandABUS
-
Model / MPNIPCA34512A
-
SKU599865
-
EAN / Barcode4043158239744
-
Product familyIP Mini Tube
-
Category4 MP IP network surveillance camera (mini-tube / bullet)
-
Image sensor1/1.8-inch Progressive Scan CMOS
-
Maximum resolution2,688 × 1,520 pixels (4 MP)
-
Maximum frame rate25 fps @ 2,688 × 1,520
-
Lens (fixed)2.8 mm
-
Horizontal field of view104°
-
Vertical field of view54°
-
Day/NightICR with automatic switching
-
IlluminationInfrared LEDs + White-light LEDs (full-color night mode)
-
Illumination rangeUp to 30 m (manufacturer specification)
-
Video codecsH.264, H.265, MJPEG
-
StreamsThree simultaneous video streams
-
Stream examplesStream 1: 2,688×1,520 @25 fps; Stream 2: 640×480 @25 fps; Stream 3: 1,920×1,080 up to 10 fps (with VCA disabled)
-
Network interface1 × RJ45 10/100 Mbps (self-adaptive)
-
PoEYes, IEEE 802.3af
-
Power input12 V DC (±25%) or PoE
-
Power consumption≈7 W (typ.)
-
Current consumption~600 mA (at 12 V DC)
-
ONVIFSupported
-
Mobile accessABUS Link Station compatible
-
Local storagemicroSD slot (local recording, encrypted storage supported)
-
AudioAudio support listed by distributor (details not specified by ABUS)
-
VCA / AnalyticsHuman detection, vehicle detection, tripwire, intrusion, area entry/exit
-
Ingress protectionIP67 (weather-resistant)
-
Housing materialMetal
-
Housing colorWhite
-
Dimensions (L×W×H)179 × 74 × 75 mm
-
Operating temperature≈ −30 °C to +60 °C
-
Weight (product)~400 g (estimated)
-
Gross weight (package)0.8 kg (manufacturer datasheet)
-
Mounting styleMini-tube / bullet camera
-
CertificationsNo hazardous-area certification listed
-
Included featuresIR + white-light illumination, encrypted microSD recording, PoE, ONVIF, analytics
